RFID Tags

SmartTag Smallest

SmartTag Smallest is a major work from SmartTag products

with great performance on metal and is best selling product

compared to other similar sized metal tags.


SmartTag Smallest for Unparalleled Robust Metal Mounting Solution


Dimensions

Length 38mm (1.5 in.) / Width : 10mm (0.4 in.) / Thickness : 3mm (0.1 in.) / Hole diameter : 2mm (0.07 in.)



Memory and Storage

96 up to 480 bits EPC, 64 bit TID, 512 bit programmable user memory

Read Range

Fixed reader : On non-metal 0.5m / On metal 2.5m
Handheld reader : On non-metal 0.3m / On metal 1.0m


Environment

Humidity :
5 % to 95 % RH Non-condensing
Vibration and Shock protection :
Withstands standard material handling vehicle environments.
Meets or Exceeds MIL STD 810 F
IEC60068-2-6/64 (Vibration), IEC60068-2-31 (Drop&Topple), IEC60060-2-11 (Salt water)
Thermal Cycling :
-45 to 85 C
Environmental Protection : Sealed to IP68 (water and dust tight)
